| TYPE OF CAMERA |
| Type of Camera |
Compact digital still camera with built-in flash, 7.0x Optical/3.2x Digital/ 22x Combined Zoom |
| IMAGE CAPTURE DEVICE |
| Type |
2/3" Charge-Coupled Device (CCD) |
| Total Pixels |
Approx. 8.3 million |
| LENS |
| Focal Length |
7.2 - 50.8mm, f/2.4 - 3.5 zoom lens(35mm film equivalent: 28 - 200mm) |
| Digital Zoom |
3.2x |
| Focusing Range |
Normal:
50cm (1.6 ft.) - Infinity (W - 63mm equivalent)
1m (3.3 ft.) - Infinity (63mm equivalent - T)
Normal+Tele-converter:
2.2m (7.2 ft.) - Infinity (126mm equivalent - T)
Normal+Close-up Lens:
33 - 50cm (1.1 - 1.6 ft.) (T)
Macro:
10 - 50cm (3.9 in. - 1.6 ft.) (W - 63mm equivalent)
30 - 50cm (1.0 - 1.6 ft.) (63 - 90mm equivalent)
Super Macro:
3 - 30cm (1.2 in. - 1.0 ft.) (42 - 90mm equivalent)
Manual:
10cm (3.9 in.) - Infinity (W - 63mm equivalent)
30cm (1.0 ft.) - Infinity (63mm - 90mm equivalent)
1m (3.3 ft.) - Infinity (90mm equivalent - T) |
| Autofocus |
1-point AF (Center Point or FlexiZone AF is available according to shooting mode) |
| VIEWFINDERS |
| Optical Viewfinder |
Not available |
| LCD Monitor |
2.0" TFT color LCD with variable-angle function.
Approx. 235,000 dots |
| LCD Coverage |
100% |
| APERTURE AND SHUTTER |
| Maximum Aperture |
f/2.4 - 8.0 (W), f/3.5 - 8.0 (T) |
| Shutter Speed |
15 - 1/4,000 sec. |
| EXPOSURE CONTROL |
| Sensitivity |
AUTO; ISO 50/100/200/400 equivalent |
| Light Metering Method |
Evaluative/Center-weighted average/Spot |
| Exposure Control Method |
Program AE, Shutter-Priority AE, Aperture-Priority AE, Manual |
| AE Lock |
Available |
| ND Filter |
Available (On: Approx. three stops reduction) |
| WHITE BALANCE |
| White Balance Control |
Auto, Pre-set (Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H, Flash), or Custom White Balance(2 positions) |
| FLASH (BUILT-IN) |
| Operation Modes |
Auto, Red-Eye Reduction On/Off |
| Flash Range |
WIDE: 50cm - 5.0m (1.6 - 16.4 ft.)
TELE: 1m - 3.5m (3.3 - 11 ft.)
(When sensitivity is set to ISO 100 equivalent) |
| Recycling Time |
Approx. 10 sec. or shorter (battery voltage=7.4V) |
| Terminals for External Flash |
Sync-terminals at accessory shoe.Automatic E-TTL Flash is possible with EX-series Speedlites: Canon Speedlite 550EX, 420EX, 380EX, 200EX, Macro Ring Lite MR-14EX and Macro Twin Lite MT-24EX. |
| Flash Exposure Compensation |
+/- 2.0EV (at every 1/3-stop) |
| SHOOTING SPECIFICATIONS |
| Shooting Modes |
Auto, Creative (P, Av, Tv, M, Custom 1, Custom 2), Image zone (Portrait, Landscape, Night Scene, Stitch Assist, Movie) |
| Self-Timer |
Operates with approx. 2 sec. or approx 10 sec. count-down |
| Wireless Control |
Available (playback is available too) |
| Continuous Shooting |
High Speed: Approx. 2.5 images/sec., Normal: Approx. 1.0 images/sec.(at Large/ Fine mode and LCD monitor is OFF) |
| Photo Effects |
Effect off, Vivid, Neutral, Low Sharpening, Sepia, Black & White and Custom effect |
| IMAGE STORAGE |
| Storage Media |
CompactFlash (CF) Card Type I or Type II |
| Print Order Format |
Design rule for camera file system, Digital Print Order Format (DPOF) Version 1.1 |
| Image Recording Format |
Exif2.21 (JPEG)/ RAW |
| JPEG Compression Mode |
SuperFine, Fine or Normal |
| Number of Recording Pixels |
Still Image: 3,264 x 2,448 (Large), 2,272 x 1,704 (Medium 1), 1,600 x 1,200 (Medium 2), 1,024 x 768 (Medium3), 640 x 480 (Small)
Movie: 640 x 480, 320 x 240, 160 x 120 |
| NUMBER OF RECORDABLE IMAGES |
| Menu Selection | File Size(KB) | Resolution
(pixels) | 32MB | 64MB | 256MB | 512MB | 1GB |
|---|
| Large/SuperFine |
3,436 |
3,264 x 2,448 |
8 |
17 |
72 |
144 |
300 |
| Large/Fine |
2,060 |
3,264 x 2,448 |
14 |
29 |
120 |
240 |
496 |
| Large/Normal |
980 |
3,264 x 2,448 |
30 |
62 |
252 |
503 |
1,024 |
| Medium 1/SuperFine |
2,002 |
2,272 x 1,704 |
14 |
30 |
123 |
247 |
512 |
| Medium 1/Fine |
1,116 |
2,272 x 1,704 |
27 |
54 |
222 |
442 |
910 |
| Medium 1/Normal |
556 |
2,272 x 1,704 |
54 |
110 |
443 |
879 |
1,726 |
| Medium 2/SuperFine |
1,002 |
1,600 x 1,200 |
30 |
61 |
246 |
491 |
993 |
| Medium 2/Fine |
558 |
1,600 x 1,200 |
54 |
109 |
440 |
879 |
1,726 |
| Medium 2/Normal |
278 |
1,600 x 1,200 |
108 |
217 |
868 |
1,734 |
3,283 |
| Medium 3/SuperFine |
570 |
1,024 x 768 |
53 |
107 |
431 |
855 |
1,726 |
| Medium 3/Fine |
320 |
1,024 x 768 |
94 |
189 |
762 |
1,522 |
2,982 |
| Medium 3/Normal |
170 |
1,024 x 768 |
174 |
349 |
1,390 |
2,741 |
4,687 |
| Small/SuperFine |
249 |
640 x 480 |
120 |
241 |
962 |
1,891 |
3,845 |
| Small/Fine |
150 |
640 x 480 |
196 |
393 |
1,563 |
3,112 |
5,468 |
| Small/Normal |
84 |
640 x 480 |
337 |
676 |
2,720 |
5,203 |
8,202 |
| RAW |
9,020 |
2,592 x 1,944 |
2 |
6 |
26 |
54 |
115 |
*These figures reflect standard shooting conditions established by Canon.Actual totals and file sizes may vary according to the subject, shooting conditions and shooting mode. |
| TIME OF RECORDABLE MOVIES |
| Resolution
(pixels) | 32MB | 64MB | 256MB | 512MB | 1GB |
|---|
| Movie/High |
640 x 480 |
30 sec. |
61 sec. |
249 sec. |
449 sec. |
1,024 sec. |
|---|
| Movie/Medium |
320 x 240 |
91 sec. |
183 sec. |
735 sec. |
1,451 sec |
2,733 sec. |
|---|
| Movie/Low |
160 x 120 |
242 sec. |
489 sec. |
1,954 sec. |
3,902 sec. |
6,562 sec. |
|---|
*Above-written figures are measured under Canon's standard conditions and may vary depending on the scene, subjects or camera settings. Total length of movie files recordable on specific CF cards; Individual movie clips are limited to 3 minutes maximum per clip. |
| PLAYBACK SPECIFICATIONS |
| Playback Modes File |
Single, Index (9 thumbnail images), Magnification (approx. 2.0x to 10x), Movie |
| ERASING SPECIFICATIONS |
| Erase Modes |
Erase Modes Still Images: Single Image, All ImagesMovie: Part of Movie, All Movie |
| INTERFACES |
| Computer Interface |
Universal Serial Bus (USB) (mini-B jack) |
| Video Out |
NTSC or PAL |
| Audio Out |
Monaural |
| Other |
CF card slot (accepts Type I and Type II cards). Direct connection to Canon Card Photo Printers and select BJ Printers (no computer required) |
| POWER SUPPLY |
| Power Source |
1. Rechargeable Lithium-ion battery (type: BP-511or BP-512)
2. AC adapter (type: CA-560)
3. Car battery adapter (type: CR-560)
4. Coin-type secondary Lithium battery (CR-2016) |
Shooting Capacity
(BP-511) |
| Number of Shots |
|---|
| Electrip View Finder | LCD |
|---|
| BP-511/ BP-512 |
Approx. 420 |
Approx. 420 |
|---|
|
Playback Time
(BP-511) |
Approx. 400 minutes (under Canon's standard conditions with full-charged battery) |
| PHYSICAL SPECIFICATIONS BP-511/ BP-512 |
| Operating Temperature |
32 - 104°F (0 - 40°C) |
| Operating Humidity |
10 - 90% |
| Dimensions (W x H x D) |
117.5 x 72 x 90.3mm(4.63 x 2.84 x 3.56 in.) (Excluding viewfinder and protrusions) |
| Weight |
Approx. 545g(19.2 oz.) (camera body only) |
