Type
|
Desktop Colour Flatbed Scanner
|
|
Scanning element
|
CIS
|
|
Light source
|
3-colour (RGB) LED
|
|
Optical resolution
|
4800x4800 dpi¹
|
|
Selectable resolution
|
25 - 19200 dpi
|
|
Interface
|
Hi-Speed USB
|
|
Scanning gradation (colour)
|
48 bit input - 48 or 24 bit output
|
|
Scanning gradation (greyscale)
|
16 bit input - 8 bit output
|
|
Maximum document size
|
A4 / Letter [216 x 297 mm]
|
|
EZ-Scan Buttons
|
5 buttons (PDF, FINISH PDF, AUTO SCAN, COPY, E-MAIL)
|
|
Preview speed
|
Approx. 9 sec.¹
|
|
Scanning speed (colour)
|
2.2 msec. per line (300 dpi), 33.2 msec.per line (4800 dpi)¹
|
|
Scanning speed (greyscale)
|
2.2 msec.per line (300 dpi), 11.1 msec.per line (4800 dpi)¹
|
|
Scanning speed (B&W)
|
2.2 msec. per line (300 dpi), 11.1 msec. per line (4800 dpi)¹
|
|
Scan speed (A4, 300dpi, Colour)
|
Approx. 10 sec.¹
|
|
Software included
|
ScanGear, Solution Menu EX, MP Navigator EX
|
|
Power supply
|
Supplied via USB port
|
|
Power consumption
|
approx. 2.5 W USB Powered (Operating)
approx. 1.4 W (Standby)
approx. 11 mW (Suspend)
|
|
Dimensions
|
250x365x39 mm
|
|
Weight
|
approx. 1.6 Kg
|
|
Operating range (temperature)
|
5 degrees C to 35 degrees C
|
|
Operating range (humidity)
|
10% to 90% RH (no dew condensation)
|
|
Operating system requirements
|
Windows 7: 1 GHz or faster cpu, 1 GB RAM (32bit) or 2 GB RAM (64bit)
Windows Vista, Vista SP1/ SP2: 1 GHz or faster cpu, 512 MB RAM
Windows XP SP2/SP3: 300 MHz or faster cpu, 128 MB RAM
Internet Explorer 6.0 or higher, CD-ROM drive, Display SVGA 800x600
Mac OS X v.10.4.11: Intel, PowerPC G5, G4 or G3 processor. 256 MB RAM
Mac OS X v.10.5: Intel, PowerPC G5, or G4 processor. 512 MB RAM
Mac OS X v.10.6 Intel processor. 1 GB RAM
Safari 3, CD-ROM drive, Display XGA 1024x768, Mac OS Extended (Journalled) or Mac OS format hard drive
|
|
Optical resolution
|
¹ Optical resolution is a measure of maximum hardware sampling resolution, based on ISO 14473 standard
|
|
Preview speed
|
¹ Preprocessing time is not included
|
|
Scanning speed (colour)
|
¹ The fastest speed in Hi-Speed USB on Windows PC. Transfer time to computer is not included
|
|
Scanning speed (greyscale)
|
¹ The fastest speed in Hi-Speed USB on Windows PC. Transfer time to computer is not included
|
|
Scanning speed (B&W)
|
¹ The fastest speed in Hi-Speed USB on Windows PC. Transfer time to computer is not included
|
|
Scan speed (A4, 300dpi, Colour)
|
¹ Colour document scan speed is measured with ISO/IEC 24735 Annex C Test Chart A. Scan speed indicates the time measured between pressing the scan button of the scanner driver and the on-screen status display turns off. Scan speed may vary depending on system configuration, interface, software, scan mode settings and document size etc.
|
