| Type |
|---|
| Camera Type |
Spherical camera |
| Sensor |
|---|
| Size |
1.0"-type (13.2mm x 8.8mm) x 2
|
| Effective Pixels |
Output size: Approx. 20MP (x2)
|
| Still |
RAW: 7296 x 3648
JPEG: 6720 x 3360
|
| Movie |
4K: 3840×1920/29.97fps/56Mbps
2K: 1920×960/29.97fps/16Mbps
|
| Sensitivity |
Still image, Video, Live streaming: ISO80 to 6400
|
| Shake Reduction |
3-axis rotational stabilization while shooting videos
|
| White Balance |
Still image: Auto, outdoors, shade, cloudy, incandescent lamp 1, incandescent lamp 2, daylight color fluorescent lamp, natural white fluorescent lamp, white fluorescent lamp, light bulb color fluorescent lamp*
Video: Auto
Live streaming: Auto
* A smartphone is required to change modes or configure manual settings.
|
| Lens |
|---|
| Construction |
14 elements in 10 groups
|
| Aperture |
F2.1, 3.5, 5.6
|
| Shooting distance |
Approx. 40cm to infinity (from front of lens)
|
| Focusing System |
|---|
| Type |
Fix Focus
|
| Liveview |
|---|
| LiveView |
A smartphone with a dedicated App is required
|
| Shutter |
|---|
| Speed |
| Auto: |
1/25000 to 1/8 |
| Shutter Priority: |
1/25000 to 1/8 |
| Manual: |
1/25000 to 60 sec |
| Video: |
1/25000 to 1/30sec |
| Live Streaming: |
1/25000 to 1/30sec |
|
| Exposure system |
|---|
| Exposure Control |
Exposure control mode: Auto |
| Exposure Modes |
Program AE, Aperture Priority AE, ISO Priority AE、Shutter Priority AE、Manual Exposure
|
| Compensation |
Still image: Manual compensation (-2.0 to +2.0EV, 1/3EV step) *
* A smartphone is required to change modes or configure manual settings.
|
| Exposure Parameters |
|---|
| Modes |
Still image: Auto, shutter priority, ISO priority and manual*
Video: Auto
Live streaming: Auto
* A smartphone is required to change modes or configure manual settings.
|
| Movie |
|---|
| Recording |
Shooting mode: Auto
ISO sensitivity: ISO 80 to 6400
White balance: Auto
Shutter speed: 1/25000 to 1/30 second
Storage capacity*1: (time per recording): Maximum 25 minutes or upper limit 4GB of the file size*2
(total recording time): Approx. 40 minutes (4K), approx. 130 minutes (2K)
Image file format: MP4 (video: MPEG-4 AVC/H.264, audio: AAC)
File size: 4K - 3840x1920 / 30 fps / 56Mbps
2K - 1920x960 / 30 fps / 16Mbps
*1. The number of photos and recording times are guides only. The actual number differs according to the photography conditions.
*2. Automatic shut down if the internal temperature increases.
|
| Storage |
|---|
| Internal |
approx. 19GB
|
| Storage Capacity |
- Still image: RAW+ Approx. 350 photos, JPEG Approx. 2400 photos
- Video (time per recording): Max. 5minutes/Max. 25 minutes *3 *4
- Video (total recording time):（4K）Approx. 40 minutes, （2K) Approx. 130 minutes
|
| File Format |
Still image: JPEG (Exif Ver. 2.3)
Video: MP4 (video: MPEG-4 AVC/H.264, audio: AAC)
Live streaming (USB): MPEG-4 AVC/H.264, Audio: AAC-LC(monaural
|
| Special Features |
|---|
| Features |
Usage temperature range: 0°C - 40°C
Usage humidity range: 90% or less
Storage temperature range: -20°C - 60°C
Communications protocol (WLAN): HTTP
Communications protocol (BLE): GATT
|
| Wireless LAN |
|---|
| Standards |
HTTP (Open Spherical Camera API v2）
IEEE802.11 a/b/g/n/ac (2.4GHz/5GHz）
IEEE802.11 b/g/n (2.4GHｚ Only）
*That differs depending on the region.
|
| Frequency (Center Frequency) |
2400MHz - 2483.5MHz
5150MHz - 5250MHz
2.4GHz:1 - 11ch or 1 - 13ch *5
5GHz:W52（36 - 48ch, Channel bandwidth 20/40/80MHz）
*That differs depending on the region.
|
| Bluetooth |
|---|
| Standards |
Bluetooth low energy technology using GATT（Generic Attribute Profile）
|
| Interface |
|---|
| Interface |
External interface: USB3.0, USB Type-C,
|
| Power |
|---|
| Source |
Lithium-ion battery (built in)*
* Charge the battery by connecting it to a PC using the supplied USB cable.
|
| Performance |
Approx. 300 photos* or 60 minutes video
* The number of photos that can be taken is a guide based on Ricoh's measurement method (wireless on, one photo taken every 30 seconds and transferred to smartphone). The actual number differs according to usage conditions.
|
| Body |
|---|
| Height |
132.5mm
|
| Width |
48mm
|
| Depth |
29.7mm
* Excluding lens section.
|
| Weight |
Approx. 182g
|
| Accessories |
|---|
| Kit Content |
USB cable
Soft case
|
| Optional |
| LENS CAP TL-2 |
30278 |
| SEMI-HARD CASE TS-2 |
39892 |
| STRAP ATTACHMENT AT-1 |
38371 |
| EXTENSION ADAPTER TE-1 |
37861 |
|
