Canon XEED WUX5000

Article No.: 5748B003-kit

Canon XEED WUX5000

Article No.: 5748B003-kit

Out of stock

The advanced WUXGA, 5000 lumens installation projector.

The XEED WUX5000 benefits from LCOS technology delivering 5000 lumens, WUXGA resolution, Full HD support and motorised interchangeable lenses – redefining image quality for installation projectors.

Native WUXGA resolution and Full HD capability (1080p)
LCOS technology
5000 lumens
1000:1 contrast ratio
Motorised lens shift, zoom and focus
3 interchangeable lens options
Advanced RGB and gamma adjustment
DVI and HDMI inputs
PJLink compatible Network port

Perfect combination for great image quality

The XEED WUX5000 raises the quality bar for installation projectors. Projecting at WUXGA resolution (1920 x 1200 pixels) it delivers images from PC or Macintosh with exceptional clarity and reproduces Full HD video in perfect detail. Canon LCOS technology delivers stunning image quality, which overcomes the typical side-effects of conventional image projection that causes unwanted ‘lattice’ or ‘rainbow’ effects.

Exceptional performance

The XEED WUX5000 employs the latest generation of Canon’s AISYS optical system, delivering a powerful 5000 lumens for all content, irrespective of colour. AISYS optimises the performance of the LCOS panels, for results that achieve “real” colour brightness. A high 1000:1 contrast ratio ensures vivid colours and excellent black levels. Delta-E colour matching is exceptional and very close to professionally calibrated devices.

Canon’s interchangeable motorised lenses

A range of high-quality motorised interchangeable lenses are available for the XEED WUX5000. The standard 1.5x zoom lens is ideal for most installations, while a 1.7x long-focus zoom lens is available for larger venues. The ultra-wide fixed lens is perfect for rear projection. Canon’s High-quality lenses have been designed specifically to maximise brightness with exceptional image definition and geometry.

Advanced installation features

For easy operation the motorised zoom, focus and lens shift features can be altered by the remote control to an accuracy of half a pixel. The XEED WUX5000 has the perfect control necessary for single or multiple projector installs, such as 3D, stacking, blended systems and domes.

Flexible integration and versatile connectivity

Both DVI-D and HDMI ports connect the XEED WUX5000 with high-definition digital sources. There's also a 15-pin VGA terminal and three mini-jacks for audio connectivity. Serial and network ports enable control and monitoring, while PJLink compatibility is ideal for integrating an AV system.

Easy maintenance

Maintenance has never been quicker or easier. The high-efficiency lamp has a lifespan of up to 3000 hours and is easily accessed from the rear of the projector. The air filter simply slides out from the side. Quick access is also provided to key optical components so there's no need for complex dismantling.

PANEL

Type	LCOS reflective display, TFT Active Matrix
Size and Number	0.71” diagonal (15.4mm x 9.6mm), 3 panels
Aspect Ratio	16:10
Native Resolution	1920 x 1200 (WUXGA), 2304000 pixels

OPTICS

Lamp Type	330W NSHA
Lens F Number and Focal Length	F1.89 – F2.65; f=23.0 – 34.5mm (Lens RS-IL01ST)
Zoom Magnification and Control	1.5x Motorised
Focus Control	Motorised
Lens Shift	Vertical: 3.5:6.5 to 10.5:-0.5 (-15% to +55%) Motorised Horizontal: 4:6 to 6:4 (+/-10%) Motorised

IMAGE AND AUDIO

Brightness	5000 lumens
Brightness Uniformity	88%
Contrast Ratio	1000:1 (full on / full off)
Projection Distance Coverage	1.3m – 29.0m (3.2m - 4.8m for 100" image, Lens RS-IL01ST)
Screen Size	40” - 600” (86 x 54cm - 1292 x 808cm)
Digital Zoom Magnification	1x – 12x
Keystone Correction Range	Vertical: +20° to -11° Horizontal: +/-20°
Digital RGB Compatibility	WUXGA / UXGA / WSXGA+ / SXGA+ / WXGA+ / WXGA / SXGA / XGA / SVGA / VGA
Analogue RGB Compatibility	WUXGA / UXGA / WSXGA+ / SXGA+ / WXGA+ / WXGA / SXGA / XGA / SVGA / VGA
Digital Video Scan Systems	1080p / 1080i / 720p / 576p / 480p
Component Video Scan Systems	1080p / 1080i / 720p / 576p / 576i / 480p / 480i
Video / S-Video Colour Systems	PAL / PAL-M / PAL-N / NTSC / NTSC4.43 / SECAM
Scanning Frequency	Horizontal: 15-75kHz, Vertical: 50-85Hz, Clock: 162MHz
Display Modes	Standard, Presentation, Dynamic, Vivid Photo, Photo/sRGB, Video, Cinema, Custom (with 5 presets)
Image Enhancement	12-bit Digital Gamma Correction
Built-in Speaker	5.0W RMS, Monaural

PORTS AND CONNECTORS

Digital RGB Input	DVI-D 24-pin
Digital Video and Audio Input	HDMI V1.3 (with Deep Colour)
Analogue RGB Input	Mini D-Sub 15-pin (Component via optional adaptor cable)
Audio Input 1	3.5mm stereo mini-jack
Audio Input 2	3.5mm stereo mini-jack
Audio Output	3.5mm stereo mini-jack (variable level)
Service Port / Projector Control	Mini D-Sub 9-pin
Network Port	RJ-45

MECHANISMS

Front Elevation Mechanism

Two rotary feet, 6° maximum image elevation

RATINGS

Dimensions (W x H x D)	380mm x 170mm x 430mm
Weight	8.5kg (without lens)
Power Source	100V - 240V AC, 50/60Hz
Power Consumption	Normal Mode: 450W / Standby: 1.7W / Standby (LAN off): 0.35W
Noise Level	Normal Mode: 40dBA
Operating Environment	+5°C to +35°C
Storage Environment	-10°C to +60°C
Warranty	3 years
