Canon i-SENSYS FAX-L170

Article No.: 5258B003-4960999783697

Canon i-SENSYS FAX-L170

Article No.: 5258B003-4960999783697

Out of stock

The easy-to-use, stylish and compact, laser fax machine

This compact Super G3 fax is effortless to use and maintain. Offering superb energy efficiency with a range of professional fax features it’s the ideal solution for small and medium-sized businesses.

Compact and stylish Super G3 fax
512-page* transmit and receive fax memory
30 one-touch and 100 coded speed dials
30-page Automatic Document Feeder
Easy-to-use intuitive LCD display
All-in-One cartridge
Energy efficient
Built-in handset

* Based on ITU-T Standard Chart No. 1

Gift

Info

Delivery time

Kifutott termék, már nem rendelhető. - No Longer Available.

Article No.

5258B003-4960999783697

Details

Quick, efficient faxing

This Super G3 fax can cut your communication costs down to a minimum. It transmits documents in as little as 3 seconds per page*. With faxes sent and received in the shortest time possible, the telephone line is freed up.

Effortless faxing

If paper or toner run out, a 512-page* memory safely stores all incoming documents so you can print out faxes later. For easier operation, lengthy documents can be scanned into the memory and sent automatically – saving time and money.

Simple, fast dialling

Even inexperienced users will find i-SENSYS FAX-L170 easy to operate. Dialling couldn’t be simpler with 30 one-touch and 100 coded speed dials storing all your regular numbers. A clear, intuitive LCD display makes this fax particularly easy to use.

Easier workflow

Users can fax or copy lengthy documents smoothly, in a single operation, rather than feeding them through a page at a time – thanks to the 30-page Automatic Document Feeder. A 150-sheet capacity paper tray also saves time refilling paper.

Fast printing and copying

Use this fax as a productive 18-pages-per-minute laser printer via the USB connection. With Quick First Print technology, there is a fast warm-up time from sleep mode. You can also copy documents at 11.8 pages per minute.

Minimum maintenance

The i-SENSYS FAX-L170’s All-in-One cartridge, which contains toner, drum and all essential parts, can be replaced in seconds. There's no mess or hassle, and by using an Authentic Canon Cartridge, you can be sure of continuous high quality output.

Leading energy efficiency

This environmentally friendly fax has class-leading energy efficiency, consuming only 1.5 watts in sleep mode.

Built-in handset

i-SENSYS FAX-L170 has a handset for making and answering calls, with automatic Fax/Tel switching between faxes and voice calls.

* Based on ITU-T Standard Chart No. 1

FAX UNIT TYPE

Type	Standalone facsimile & Laser printer
Compatibility	Group 3
Applicable line	PSTN
Modem speed	33.6K bps (Super G3)
Print technology	Laser beam printing
Scanner type	Sheet fed

FAX SCANNING FEATURES

Automatic document feeder	30 sheets
Document size	Width - 216mm(Max), 139.7mm(Min) Length – 356mm(Max), 127mm(Min)
Effective scanning width	214mm
Scanning speed	Approx. 3.4 sec/page Approx. 15.8 pages/minute
Fax resolution	Up to 200 x 400 dpi
Image processing system	UHQ (Ultra High Quality)
Halftone	256 shades of grey scale

FAX PRINTING FEATURES

Printing method	Laser Beam Printing
Print speed	18 pages per minutes
First Print Out Time	7.8 secs
Print resolution	600 x 400 dpi
Print Quality	Up to 1200 x 600 dpi
Paper capacity	150 sheet
Print cartridge	CRG728 All in One cartridge
Cartridge Yield	approx. 2100 pages ¹²
Page collated print	Yes ( Face down print )
Paper output tray capacity	100 sheets
Media Types	Plain, heavy, Recycled, Transparecy, Label, Envelope
Media Sizes	Cassette: A4, B5, A5, LGL, LTR, STMT, EXE, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, FLS, 16K, Postcard, Envelope: COM10, Monarch, C5, DL, Custom (Min. 76.2 x 127mm to Max. 216 x 356mm) ADF: A4, B5, A5, B6, Letter, Legal, Statement, Min. 127 x 139.7 mm to Max. 216 x 356 mm
Printing width	206mm
Toner save mode	Yes
Auto image reduction on reception	Yes (100 to 75% 1% increments)

TRANSMISSION AND RECEPTION FEATURES

Transmission speed	3 seconds per page with 33.6K bps modem ¹
Compression method	MH, MR, MMR
Memory transmission	Yes
FAX memory	512 pages ¹
Memory backup	5 mins
Memory reception	Yes
Dual access	Yes
Error correction mode(ECM)	Yes
Delayed transmission	Yes ( 140 locations )
Sequential broadcast	Max. 140 destinations
Reception	Yes
Sub-address tranmission	Yes
Error re-transmission	Yes
Fax transfer	Yes

SECURITY AND MANAGEMENT FEATURES

Forced memory reception	Yes
Reports	Activity Management Report (TX/RX), Activity Result Report
Transmission header	Yes
Reception footer	Yes

TELEPHONY FEATURES

One-touch dials	30
Coded dials	100
Group dials	Max. 129 dials / Max. 129 destinations
Program dial	Yes
Redial	Yes ( automatic and manual )
Dial search	Yes
FAX/TEL auto switch	Yes
Answering machine Hook-up	Yes
Remote reception	Yes
On Hook key	Yes
Telephone handset	Yes
Type	Standard

COPIER FEATURES

Copy resolution	TEXT/PHOTO mode, TEXT mode, PHOTO mode: 600 dpi × 600 dpi
Copy speed ( Mono )	11.8 pages per minutes
Multiple copy	Up to 99 copies
Zoom	50% - 200% in 1% increments
First copy output time (FCOT)	Less than 22.3 secs

OTHER FEATURES

Display type	LCD
Display size	5 lines
LCD Display Languages	23 languages: (English/ Spanish/ French/ Italian/ Hungarian/ Dutch/ Norwegian/ Polish/ Greek/ Estonian/ Croatian/ Bulgarian/ Portuguese/ Slovene/ Slovak/ Finnish/ Swedish/ Turkish/ Russian/ Czech/ Danish/ German/ Romanian)
Energy saver key	Yes

PRINTER FEATURES

Interface	USB 2.0 Hi-Speed
Printer Language	UFRII-LT
Memory	64MB
Printer	Windows 2000/ XP/ VISTA/ 7 MAC OS X 10.4.9 - 10.7 ¹ Linux ¹ ²
Supplied Drivers	Printer Driver, FAX Driver

GENERAL FEATURES

Duty Cycle	Max 8,000 pages per month
Warm-Up time	Approx. 14 seconds or less from power on
Recovery time	Approx. 3.5 seconds
Dimensions (cassette closed) W x H x D	372 x 303 x 303 mm
Installation space (including trays)	572 x 724 x 520 mm
Weight	Approx. 8.8kg
Power consumption	Maximum: 1020W Active: 400W Standby: 10W Sleep: 1.5W Typical Electricity Consumption (TEC): 0.6 kWh/w
Noise Levels	Sound Power: Active: 6.5 B Standby: 4.3 B or less Sound Pressure: Active: 53 dB Standby: Inaudible
Operating Environment	Temperature: 50 to 86°F (10 to 30°C) Humidity: 20% to 80% RH (no condensation)
Power Source	220-240 V (±10%), 50/60 Hz (±2 Hz)
Cartridge Yield	¹ Based on ISO/IEC 19752 ² Ships with 1,000 pages starter cartridge
Transmission speed	¹ Based on ITU-T Standard Chart No. 1
FAX memory	¹ Based on ITU-T Standard Chart No. 1
Printer	¹ Web distribution only ² Linux support printing only.

All specifications subject to change without notice
